Dell PowerEdge R960 Rack Server 2x Intel Xeon Gold 6418H 2.1G 24C/48T 16GT/s 60M Cache DDR5 Stock Data Center Server

1 / 5

Dell PowerEdge R960 Rack Server 2x Intel Xeon Gold 6418H 2.1G 24C/48T 16GT/s 60M Cache DDR5 Stock Data Center Server

Send Inquiry

Product Description

PowerEdge R960 Rack Server - Premium Customization

Accelerate compute-intensive, high-performance core workloads

The R960 boosts business-critical operations with unprecedented scale-up capabilities in a 4U air-cooled form factor with four (4) Intel Xeon® Scalable Processors to empower business and drive data-driven initiatives.

With a maximum CPU core count of 60 cores and the ability to support 64 DDR5 DIMMs for a total of 16 TB of memory, the R960 is positioned for the largest in-memory databases without the need for slower I/O database access.
Scale up business needs with support for up to 24 NVMe drives, DDR5 DIMMs, 12 PCIe Gen5 slots for I/O expansion, LOM, and industry standard OCP to enable customers flexible network connectivity.
Enable fast 1:1 CPU-I/O communications with PCIe Gen5 adaptor support.

Business-critical performance, business-wide

Harness latest generation technologies to maximize data transformation, support large in-memory databases, and generate faster insights to drive the business forward.
Leverage new workload accelerators built into each Intel Xeon processor that are purpose-designed for peak performance in traditional and emerging business applications.
Install up to 4 GPU accelerators to boost AI-based business applications and rapidly transform real-time data and analytics into decision-based outcomes.
Increase power user and worker productivity with up to 4 VDI accelerators.

Technical Specifications

Specification	Details
Model	PowerEdge R860
Processor	Up to 4 x 4th Generation Intel Xeon Scalable processor with up to 60 cores per processor and with optional Intel® QuickAssist Technology
Memory	DIMM Speed Up to 4800 MT/s Memory Type RDIMM Memory Module Slots 64 DDR5 DIMM slots Maximum RAM RDIMM 16 TB
Storage	Front Bay: Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 61.44 TB / Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB / Up to 16 x 2.5-inch NVMe (SSD) max 245.76 TB / Up to 24 x 2.5-inch NVMe (SSD) max 368.64 TB / Up to 24 x 2.5-inch SAS/SATA (HDD/SSD) including up to 8 x 2.5-inch NVMe (SSD) max 245.76 TB Mid Bay: N/A Rear Bay: Up to 2 x 2.5-inch SAS/SATA (HDD/SSD) max 15.36 TB
Storage Controllers	Internal Controllers PERC H965i, PERC H755, PERC H355, HBA355i, HBA465i External Controllers PERC H965e, HBA355e, HBA465e Software RAID S160 Internal Boot Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs USB
Power Supplies	1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant 1400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant 1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant 2400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant 2800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant Fans: Up to 6 fans
Slots	Eight PCIe slots: Slot 1: 1 x16 Gen5 or 1 x8 Gen4 Full height, Half length Slot 2: 1 x16 Gen5 or 1 x8 Gen4 Full height, Half length Slot 3: 1 x16 Gen5 Low profile, Half length Slot 4: 1 x16 Gen5 Full height, Half length Slot 5: 1 x16 Gen5 Full height, Half length Slot 6: 1 x16 Gen5 Low profile, Half length Slot 7: 1 x16 Gen5 or 1 x8 Gen4 Full height, Half length Slot 8: 1 x16 Gen5 or 1 x8 Gen4 Full height, Half length

Core Features & Capabilities

Cyber Resilient Architecture

Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factory-to-site integrity assurance. Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor Authentication (MFA) and role-based access controls ensure trusted operations.

Autonomous Collaboration

The OpenManage™ systems management portfolio delivers a secure, efficient, and comprehensive solution for PowerEdge servers. Simplify, automate and centralize one-to-many management with the OpenManage Enterprise console and iDRAC.

Sustainability Focused

From recycled materials in our products and packaging, to thoughtful, innovative options for energy efficiency, the PowerEdge portfolio is designed to make, deliver, and recycle products to help reduce the carbon footprint and lower your operation costs.

PowerEdge R960 Application Scenarios

The PowerEdge R960 is a high-performance server designed to boost outcomes for core applications such as:

Large in-memory databases including SAP HANA, SQL, and Oracle
Complex Data Analytics & High-Performance Computing
AI development, virtualization, and advanced VDI workloads

Operations & Quality Control

Frequently Asked Questions

Q1: What are the main target workloads for the PowerEdge R960?

A1: The PowerEdge R960 is engineered to handle core, compute-intensive applications. It is ideal for large-scale in-memory databases (such as SAP HANA, Oracle, and SQL), heavy data analytics, high-performance computing (HPC), artificial intelligence (AI), and high-density virtualization/VDI deployments.

Q2: How does the server optimize database performance?

A2: The server features support for up to 64 DDR5 DIMMs for a maximum capacity of 16 TB of memory. This allows massive databases to run entirely in-memory, avoiding the latency and performance drops associated with slower I/O disk storage access.

Q3: What storage options and drive interfaces are supported?

A3: The platform supports up to 24 NVMe SSDs, SAS/SATA drives, and the latest Gen5 interfaces, reaching a maximum configuration storage capacity of over 368 TB. Additionally, it offers multiple internal PERC and HBA RAID controller configurations.

Q4: What built-in security features does the cyber-resilient architecture provide?

A4: The architecture provides end-to-end security starting from the supply chain through production. It features a silicon-based root of trust for boot resilience, Multi-Factor Authentication (MFA), role-based access controls, and active system protection features to guarantee a secure Zero Trust IT environment.

Q5: What are the main management tools included with the system?

A5: It includes the comprehensive OpenManage systems management portfolio, allowing administrators to manage, monitor, and automate routine server operations. Centralized one-to-many administrative oversight is achieved using the OpenManage Enterprise console paired with internal iDRAC controllers.

Q6: Does this server support high-density expansion and GPU accelerators?

A6: Yes, it is designed with 12 PCIe Gen5 slots for outstanding I/O flexibility and expansion. It can also support up to 4 high-performance GPU accelerators, making it perfectly suited for handling complex AI models and graphical VDI workloads.
