High-performance computing architecture optimized for AI workloads.
| System Architecture | Chipset: GB10 Grace Blackwell Superchip Combines a 20-core Arm CPU with a Blackwell GPU via NVLink-C2C interconnect Coherent unified memory architecture for CPU-GPU data sharing |
| CPU | 20-core Arm v9 processor 10× Cortex-X925 cores (high-performance) 10× Cortex-A725 cores (energy-efficient) |
| GPU | Blackwell architecture with: 6,144 CUDA cores (equivalent to RTX 5070) 5th-generation Tensor Cores (1,000 AI TOPS FP4 precision) 4th-generation RT Cores (ray tracing acceleration) |
| Video Engines | 1× NVENC (9th gen), 1× NVDEC (5th gen) |
| System Memory | 28GB LPDDR5X unified memory 256-bit interface, 273GB/s bandwidth Supports models up to 200B parameters locally, 405B parameters with dual-node clustering |
| Storage | 4TB NVMe M.2 SSD (self-encrypting) |
| Networking | ConnectX-7 Smart NIC (200Gbps RDMA for clustering) 10GbE RJ45 port Wi-Fi 7 (802.11be) + Bluetooth 5.3 |
| Interfaces | 4× USB4 Type-C (40Gbps) 1× HDMI 2.1a (supports 8K video output) Audio: HDMI multichannel audio |
| Power Consumption | 170W typical operation Up to 224W peak under heavy load |
| Physical Specs | Dimensions: 150mm (L) × 150mm (W) × 50.5mm (H) Weight: 1.2kg Form Factor: FHFL dual-slot (rack-mountable) |
| Operating System | DGX OS (Ubuntu 22.04-based) Pre-installed AI Enterprise software stack Supports: PyTorch, TensorFlow, RAPIDS |
| Security | Secure Boot and ECC memory protection Confidential computing with ARM TrustZone |
Silicon-based root of trust anchors end-to-end boot resilience. Multi-Factor Authentication (MFA) and role-based access controls ensure trusted operations in Zero Trust IT environments.
Simplify, automate and centralize management with comprehensive console tools. Designed to accelerate operations with autonomous collaboration and secure solutions.
Innovative options for energy efficiency designed to reduce the carbon footprint and lower operation costs. Built with recycled materials in products and packaging.
Designed for 24x7 enterprise data center operations, it features enterprise-grade components and energy-efficient hardware optimized for deployment at scale.
Supports Secure Boot with Hardware Root of Trust technology, provides an extra layer of security, and meets NEBS Level 3 standards for data center excellence.
The passively cooled, energy-efficient design fits a wide range of certified systems and is easy to integrate into existing data center infrastructure.
