| Item | Specification |
|---|---|
| Form Factor | 2U Rack Server |
| Processor | 1/2 × 4th/5th Gen Intel Xeon Scalable (Sapphire Rapids/Emerald Rapids) |
| Max CPU Cores | Up to 64 cores per CPU |
| Max CPU TDP | Up to 385W per CPU |
| Base Clock Range | 1.8 GHz – 3.1 GHz |
| Max Turbo Frequency | Up to 4.2 GHz |
| Chipset | Intel C741 Chipset |
| Memory | 32 × DDR5 DIMMs (up to 5600 MT/s); max capacity up to 8TB |
| Local Storage | Hot-swappable: • Up to 24 × 2.5" SAS/SATA/NVMe + 6 rear SFF • Up to 12 × 3.5" SAS/SATA + 4 rear LFF • Up to 20 × NVMe SSD (Express Bay) • Internal: 2 × M.2 SSD (RAID supported) |
| RAID | HPE Smart Array (0/1/5/6/10/50/60); VROC supported |
| PCIe Expansion | Up to 8 × PCIe 5.0 slots; 2 × OCP 3.0 FlexIO |
| GPU Support | Up to 4 double-width GPUs or 8 single-width GPUs |
| Network | OCP 3.0 LOM; optional 10/25/100GbE adapters |
| Fans | 4 × hot-swappable fans; N+1 redundancy |
| Power Supply | 1+1 redundant: 800W/1000W/1600W Platinum/Titanium hot-swap PSUs |
| Management | HPE iLO 6 |
| Dimensions (H×W×D) | 86.1 × 445 × 770 mm |
| Operating Temp | 5°C – 50°C |
