| Form Factor/Height | 2U rack-mount server |
| Processor | Up to 2x 3rd Gen Intel® Xeon® Scalable Processor Platinum Series, up to 40 cores, up to 270W TDP |
| Memory | 32 DDR4 memory slots; up to 12TB using 16x 256GB 3DS RDIMMs and 16x 512GB PMem; supports Intel® Optane™ 200 series. |
| Drives Bays | Up to 20x 3.5" or 40x 2.5" drives; Up to 36x NVMe drives; Supports 2x 7mm SATA/NVMe SSDs; 2x M.2 SATA/NVMe boot drives (RAID 0,1). |
| Expansion Slots | Up to 14x PCIe 4.0 slots, 2x OCP 3.0 slots |
| Network Interface | LOM adapter installed in OCP 3.0 slot; PCIe adapter |
| Power Supply | Dual redundant (up to 2200W Platinum), supports 336V, -48V high voltage DC. |
| System Management | Advanced BMC Management |
| Operating System | Microsoft, SUSE, Red Hat, VMware, CentOS, NeoKylin, Ubuntu, OpenEuler, etc. |
| GPU Support | Support up to 14x single-width or 4x double-width GPUs |
| Ports | Front: USB 3.1/2.0, VGA; Rear: USB 3.1, VGA, RJ-45 (management); Internal: Type-C. |
